Top Maintenance Kits for your JLG 400S and 460SJ Boom Lift: Part 2 of 10
|
|
Tiempo de lectura 4 min
SN 0300096000 to 0300203770
Other Serial Numbers
(Part 1) SN 0300000100 to 0300095999
(Part 2) SN 0300096000 to 0300203770
(Part 3) SN 0300203771 to 0300272360 excluding 0300272174 thru 0300272184
SN 1300000100 to 1300007393
SN E300000100 to E300007988 excluding E300007847
(Part 4) PVC 2001
PVC 2007
(Part 5) PVC 2101
(Part 6) PVC 2107
(Part 7) PVC 2201
(Part 8) PVC 2207
(Part 9) PVC 2301
(Part 10) PVC 2307
Table of Contents
Other Serial Numbers Maintenance Kits Aerial Boom Kits Turntable Bearing Installation Kits Aerial Lift Boom Wear Pad Kits Aerial Boom Hose Kits Decal Kits Boom Lift Filter Kits Combined Filter Kit Hydraulic/Air Filter Engine - Fuel/Engine Oil Filters Tire and Wheel Installation Kits 12 X 16.5 Tires 14 X 17.5 Tires 33/16LL x 16.1 Tires
Maintenance Kits
If you're reading this, that means you have in your possession a JLG 400S or 460SJ boom lift. This is the most comprehensive online guide for the kits that you will need throughout the machine's life. Here is our list of the most common kits that you will need for the maintenance of your JLG lift with a serial number 0300096000 to 0300203770.
Aerial Boom Kits
The boom cable kit installation part numbers that are found in your parts manual are installation items. Some installation items for JLG equipment are sold individually. That means that you don't actually purchase the kit part number, but rather all of the parts individually. In this case, the standard ANSI Installation for the 400s (part number 0271160) or the 460SJ (part number 0271159) is not recognized by the OEM anymore. Now thankfully this doesn't mean that the manufacturer has given up on you, it just means that the part number is no longer available. Sometimes this is because it is sold at the component level, but there are many different reasons that manufacturers change their part numbers over time. Buying the items is generally better at the component level anyway, since you are paying for only what you need. Say you need the Fly Boom for your 400S but can reuse all the other parts, you can purchase 0801213 and get that section of the boom! If you need the full kit or have any other questions, give us a call or an email!
From left to right: Boom, Fly (400s), Jib Lift Cylinder (Service Replacement) for 460SJ.
Turntable Bearing Installation Kits
Below are the turntable bearing kits for the 400S and 460SJ. These are the complete kits with the necessary bolts and washers. Contact us to find out more.
From left to right: Bearing kit for (SN 0300096000 through 0300161284), Bearing kit for (SN 0300161285 through 0300203770)
Aerial Lift Boom Wear Pad Kits
The wear pad kit comes in a complete kit.
Aerial Boom Hose Kits
Here are the boom hose kits for the 400S and 460SJ respectively.
Decal Kits
From left to right: Platform Decal, Platform Console Box Decal, Machine Decal.
Boom Lift Filter Kits
Combined Filter Kit
Combined Filter Kit (Hydraulic/Air and Fuel/Engine Oil)
The right filter kit for your JLG boom lift depends on the manufacturer of the machine's engine. Be sure to pay attention to the order above the products.
From left to right:
1001111000 Caterpillar Engine
1001110999 Deutz D2011 Engine (SN 0300096000 through 0300161284)
1001156539 Deutz D2011 Engine (SN 0300161285 through 0300181723) and (SN 0300182240 through 0300203770)
1001181146 Deutz TD2.9L4 Engine
1001114131 GM Engine
1001111001 Perkins Engine (without UGM)
1001114122 Perkins Engine (with UGM).
Hydraulic/Air Filter
Hydraulic/Air Filter
The right filter kit for your JLG boom lift depends on the manufacturer of the machine's engine. Be sure to pay attention to the description above the products.
From left to right:
1001109698 all Caterpillar, all Perkins, as well as Deutz D2011 Engines (SN 0300096000 through 0300161284)
1001182238 Deutz D2011 Engines (SN 0300161285 to present)
1001204451 Deutz DT2.9L4 Engines
Engine - Fuel/Engine Oil Filters
Engine Filters
The right filter kit for your JLG boom lift depends on the manufacturer of the machine's engine. Be sure to pay attention to the description above the products. The only engine filter that is still sold through JLG is the Deutz D2011 Engine filter for this machine. Contact us if you have a Caterpillar, Deutz DT2.9L4 or Perkins engine.
Tire and Wheel Installation
Last but not least, we have a list of tire and wheel installations for the 400S and 460SJ boomlift.
12 x 16.5 Tires
Below you will find the right hand and left hand 12 x 16.5 foam-filled tires. These tires make up the 0270092-installation item found in your part manual. There are also options for Pnuematic, Non-Marking, LT, and TS style tires. 12 x 16.5 tires are also available in foam-filled (non-marking) options. Give us a call if you want to find out more.
14 x 17.5 Tires
Below you will find the right hand and left hand 14 x 17.5 foam-filled tires. These tires make up the 0271998-installation item found in your part manual. This is also available in the Pnuematic and TS style tires. Give us a call if you want to find out more.
33/16LL x 16.1 Tires
The 33/16LLX16.1 tires are available in pneumatic, pneumatic TS, and foam-filled option. Unlike the other tire sizes, all four tires will be the same. Contact us if you are interested in the other two options.
There you have, folks. Now that you have a complete view of your machine's maintenance kits and tires, hopefully you can use this information to increase your success with preventative maintenance. Check out the blog post below on the recommended service tools for your 400S or 460SJ boom lift, straight from the manual!
