1001245380 Ground Control Panel, Electrical Assembly
Below, you will find the products that make up the 1001245380 Ground Control Panel, Electrical Assembly. The quantities required are below "Products" and the items and machines that this item is found in will be the table below "quantities required".
Components
Quantities Required
| Component Item | Component Description |
Quantity |
U/M |
| 1001155044 | NUT-SPEC,15/32-32 UNS-2B | 7 | EA |
| 10836804 | GAUGE, HOURMETER | 1 | EA |
| 1001274559 | SWITCH,E-STOP | 1 | EA |
|
1001245379 (Installation Item) |
MOUNT,GROUND CONTROL PANEL | 1 | EA |
| 1001155045 | SWITCH,TOGGLE SWITCH, S.P.D.T. | 7 | EA |
| 1001155043 | WASHER-SPEC,KEY POSITIONING | 7 | EA |
| 4360476 | TERMINAL, BLOCK | 1 | EA |
Single Level Where Used
Structured Inquiry
| Component Item |
Component Description |
| 1001245993 | INSTALL,ELECTRICAL SYSTEM |
| 1001245992 | INSTALL,ELECTRICAL SYSTEM |
