1001238887 Ground Control Panel Mount

A diagram of JLG part number 1001238887 Ground Control Panel Mount.

Browns Heavy Equipment |

Welcome to our installation series, a blog series dedicated to JLG installation parts. Most of the installation items you will find in your JLG parts manuals are sold at the component level. The goal of this series is to provide the components in an easy-to-locate, click-to-purchase format. Whether you are just needing an idea on the cost of the installation item, or you need these items shipped to you right away, we have you covered.

1001238887 Ground Control Panel Mount

Below, you will find the products that make up the 1001238887 Ground Control Panel Mount. The quantities required are below "Products" and the items and machines that this item is found in will be the table below "quantities required".

Components

Quantities Required

Component Item Component Description Quantity U/M
5251012 BOLT,METRIC HEX FLANGE,10X25MM 6 EA
5261000 NUT,METRIC HEX FLANGE 6 EA
1001235529 BRACE,GROUND CONTROL 1 EA
1001235528 SUPPORT,GROUND CONTROL 1 EA
1001297390 PLATE,GROUND CONTROL 1 EA

Single Level Where Used

Structured Inquiry

Component Item Component Description
1001238888S MOUNT,GROUND CONTROL
1001238888 MOUNT,GROUND CONTROL
1001239294 MOUNT,GROUND CONTROL
1001238890 ELEC ASSY,GROUND CONTROL
1001238890S ELEC ASSY,GROUND CONTROL
